V.E.L.O.C.I.T.Y.-OS: Classic Compiler Optimization Passes in JIT (Part 7)

Now that the JIT compiler could output raw x86-64 machine instructions, the next step was to optimize the AST tree before emitting code bytes.

If the model generated redundant operations, unused variables, or simple constants, I wanted to eliminate them at compile-time to keep the generated machine code as small and clean as possible.

We are building a bare-metal, self-healing operating system running entirely inside the CPU's L3 cache. Here is the roadmap for this 12-part series:

1.
   Part 1: The Spark — Exposing the "Safe-Room" security leak and building the compiler gate.


2.
   Part 2: The NDA Language — Designing a content-addressed triplet representation to cure context bloat.


3.
   Part 3: Ditching the Web Stack — Building a native 30MB IDE with 1,500,000x IPC latency drops.


4.
   Part 4: The Closure JIT — Compiling AST blocks to nested closures and bypassing borrow checker limits.


5.
   Part 5: JIT Math Optimizations — Replacing division operations with precomputed 16-bit lookup tables.


6.
   Part 6: x86-64 Assembler & SCEV-Lite — Compiling scalar loops directly to native code in constant time.


7.
   Part 7: Classic Compiler Passes — Implementing inter-procedural Dead Code Elimination and loop unrolling. (You are here)



8.
   Part 8: Reclaiming Ring 0 — Exiting UEFI boot services and transitioning the kernel to Ring 0.


9.
   Part 9: Bare-Metal Drivers — Writing a PCI scanner, NVMe block storage controller, and FAT32 parser.


10.
    Part 10: Synaptic Canvas — Rendering a spatial, force-directed GUI based on model token activation vectors.


11.
    Part 11: Swarms & Hot-Patching — Building multi-agent scheduling and zero-downtime RCU driver updates.


12.
    Part 12: Self-Evolution — Handing system control over to a local LLM Terminal that self-optimizes via telemetry.

In src/compiler/nda_jit.rs, I implemented four classic compiler optimization passes, running directly on the AST before emitting code. Here is the core AST rewriter structure for folding and loop unrolling:

// compiler/nda_jit.rs — AST Optimization Passes

fn optimize_node(node: NdaNode, var_constants: &mut HashMap<u64, i32>) -> NdaNode {

    match node {

        // Pass 1: Constant Folding on Addition operations

        NdaNode::Add { lhs, rhs } => {

            let opt_lhs = optimize_node(*lhs, var_constants);

            let opt_rhs = optimize_node(*rhs, var_constants);

            match (&opt_lhs, &opt_rhs) {

                (NdaNode::Int { value: l }, NdaNode::Int { value: r }) => {

                    NdaNode::Int { value: l.saturating_add(*r) }

                }

                _ => NdaNode::Add { lhs: Box::new(opt_lhs), rhs: Box::new(opt_rhs) },

            }

        }



        // Pass 2: Constant Propagation using compile-time tracking

        NdaNode::Load { name_hash } => {

            if let Some(&val) = var_constants.get(&name_hash) {

                NdaNode::Int { value: val } // Replace Load with direct constant Int node

            } else {

                NdaNode::Load { name_hash }

            }

        }



        // Pass 3: Loop Unrolling for small static iteration loops (<= 4 iterations)

        NdaNode::Loop { count, body } => {

            if count > 0 && count <= 4 {

                let mut unrolled = Vec::new();

                for _ in 0..count {

                    unrolled.extend(body.clone());

                }

                // Recurse to run optimization passes on the unrolled body

                let opt_unrolled = optimize_sequence(&unrolled, var_constants);

                NdaNode::Scope { children: opt_unrolled }

            } else {

                // Invalidate constant propagation tracking for loop-mutated variables

                let mut written = std::collections::HashSet::new();

                for child in &body { gather_written_vars(child, &mut written); }

                for v in written { var_constants.remove(&v); }



                let mut loop_vars = HashMap::new();

                let opt_body = optimize_sequence(&body, &mut loop_vars);

                NdaNode::Loop { count, body: opt_body }

            }

        }

        // ... other nodes

        other => other,

    }

}

Pass 1: Constant Folding

When walking the AST, the compiler checks for operations whose operands are static constants (e.g. Add(Int(5), Int(3))).

Instead of generating runtime additions, the compiler evaluates the operation during compilation and folds the expression into a single node: Int(8). I extended this to vector operations like Negate and Abs on constant values.

Pass 2: Constant Propagation

If a variable is bound to a constant integer value (e.g. let a = 1), the compiler registers this binding in a compile-time map.

Whenever a subsequent Load instruction queries that variable, the compiler replaces the Load node directly with the folded Int(1) node, bypassing memory reads completely.

Pass 3: Loop Unrolling

Condition evaluations and branching instructions add significant jump latency inside loops.

For loops with small, static iteration counts (


$count\le 4$

), the JIT compiler unrolls the loop body

$count$

times into a flat execution Scope. This completely eliminates loop counters, jumps, and branching overhead, allowing instructions to execute in a straight pipeline.

Pass 4: Inter-procedural Dead Code Elimination (DCE)

To prune unused variables and redundant operations, the compiler walks the instruction sequence backwards (from end to start).

If a variable assignment (Let or Store) is found, but the variable is never read in subsequent instructions (and has no side effects), the compiler removes the node from the tree.

Here is how the compiler pipelines these passes together to construct the final optimized AST:
